Metal Stainless Steel Bellow Compensator Flexible Expansion Joint For Industrial Pipeline

Metal Stainless Steel Bellow Compensator Flexible Expansion Joint For Industrial Pipeline
Metal Stainless Steel Bellow Compensator Flexible Expansion Joint For Industrial Pipeline Metal Stainless Steel Bellow Compensator Flexible Expansion Joint For Industrial Pipeline Metal Stainless Steel Bellow Compensator Flexible Expansion Joint For Industrial Pipeline Metal Stainless Steel Bellow Compensator Flexible Expansion Joint For Industrial Pipeline

Large Image :  Metal Stainless Steel Bellow Compensator Flexible Expansion Joint For Industrial Pipeline

Product Details:
Place of Origin: China
Brand Name: JINGNING
Certification: CE、ZTC
Model Number: JDZ
Payment & Shipping Terms:
Minimum Order Quantity: 1
Detailed Product Description
Company Type: Factory Product Name: Metal Stainless Steel Bellow Compensator Flexible Expansion Joint For Industrial Pipeline
Working Pressure: 0---6.0Mpa Bellows Material: SS304,SS316,SS321
OEM&ODM: Support Flange Material: Stainless Steel,Carbon Steel
High Light:

DN100 Stainless Steel Bellow Compensator

,

6.0Mpa Stainless Steel Bellow Compensator

,

DN100 Flexible Expansion Joint

Metal stainless steel bellow compensator flexible expansion joint for industrial pipeline



Flexible expansion joint compensator can be used to eliminate the pipelines, containers or equipment caused by climate change or other reasons caused by thermal expansion or displacement.Flexible expansion joint compensator can be installed on both ends of import and export or other high frequency mechanical pump to reduce or eliminate the vibration, improve the service life of the pipe and sealing performance. Butt welded flexible expansion joint compensator can also be used to absorb deviation of actual installation.it has reliable operation, compact structure, compensation ability is strong, resisting all kinds of medium corrosion and having long service life, etc.



Performance of flexible expansion joint



The main elastic element of flexible expansion joint is stainless steel bellows. Through the expansion and bending of bellows, the flexible expansion joint compensates the pipeline in axial, transverse and angular directions. Flexible expansion joint can play the following roles:

1. The flexible expansion joint absorbs the axial, transverse and angular thermal deformation of the pipeline.

2. Flexible expansion joint can absorb equipment vibration and reduce the influence of equipment vibration on pipeline.

3. Flexible expansion joint can absorb the pipeline deformation caused by earthquake and land subsidence.





Technique Parameter of flexible expansion joint





Main data of flexible expansion joint



Diameter

(mm)



Pressure grade
(Mpa)

Available Area of Bellows

(c㎡)



Max Size of External Diameter
(mm)



Length
(mm)



1.0

1.6

2.5

Flange
Tube
32
20/26
18/63
15/98
16
225
160/250
264/280
40
20/24
18/89
15/98
23
244
164/259
269/289
50
20/70
18/70
15/106
37
259
172/276
282/306
65
26/44
22/55
15/138
55
270
215/294
300/322
80
34/33
28/41
19/68
81
284
240/338
344/366
100
40/75
35/93
25/54
121
304
235/317
323/345
125
38/59
34/74
29/117
180
334
282/314
316/342
150
40/62
34/78
29/92
257
364
282/339
338/367
200
59/52
53/58
46/65
479
442
340/402
402/426
250
87/35
79/39
48/78
769
507
393/459
493/399
300
87/37
79/41
71/47
1105
562
464/525
564/565
350
87/44
79/48
71/45
1307
622
509/564
609/604
400
87/43
79/47
71/47
1611
562
522/566
622/628
450
87/37
79/41
47/75
1972
700
403/498
503/523
500
87/68
79/75
71/45
2445
760
431/523
531/554
600
87/85
79/94
71/82
3534
835
478/548
578/588
700
87/77
79/85
71/103
4717
1110
490
590
800
102/102
94/112
71/95
5822
1265
502
602
900
102/97
94/107
80/123
7620
1186
/
698
1000
102/105
94/106
82/117
9043
1286
/
692



Production process of flexible expansion joint



Do you know how is a high quality flexible expansion joint made?Let's see with JINGNING.

Metal Stainless Steel Bellow Compensator Flexible Expansion Joint For Industrial Pipeline 0

Flexible expansion joint can be processed into different types according to different needs

Flexible expansion joint compensator Bellow Body: Stainless Steel 304, 316L.
Flexible expansion joint bellows flange Materials: Q235 carbon steel, 304, 316L stainless steel.

Jingning has more than 17 years of design experience in manufacturing Flexible expansion joint , rubber expansion joint, metal bellows joint, disassembly joint, pipeline and other industrial pipe fittings. The Flexible expansion joint s meets the international standards such as GB, ISO, DIN, ANSI, BS, JIS and the special requirements of customers.





Flexible expansion joint advantages



1.  Flexible expansion joint is ex factory price

2. 17 years manufacturing experience, 5 years export experience

3. The flexible expansion joint has strict quality inspection, and the quality far exceeds the industry standard.

4. Various specifications of flexible expansion joint mold base customization and OEM

5. Free flexible expansion joint samples

6. Large inventory of flexible expansion joint



Flexible expansion joint application



Because of its flexibility, flexible expansion joint can compensate the temperature difference deformation or other deformation between equipment and pipeline, prevent vibration, reduce the thrust of pipeline on equipment, and adapt to the uneven settlement of oil tank foundation. The bellows expansion can be widely used in chemical industry, oil refining, electric power, light industry, atomic energy, metallurgy, machinery, instrument, ship, aerospace and other departments. With the wide application of power pipeline and heat pipeline in industry and civil field, the requirement of bellows expansion is higher and higher.
