Bellows Type Metal Expansion Joint High Temperature Resistance Flexible Connectors
Flexible connectors is a versatile alloy that combines chromium and nickel to provide excellent corrosion resistance in a variety of corrosive environments. Its resistance to oxidation at elevated temperatures makes it particularly suitable for high-temperature applications, where other materials might fail or degrade rapidly. Flexible connectors is a critical feature that allows it to accommodate thermal expansion and contraction in piping systems and other structures. The corrugated or pleated shape of the bellows enables it to flex and expand without compromising its structural integrity, thereby absorbing stresses and preventing leaks or failures in the system.
Performance of bellows expansion
The main elastic element of flexible connectors is stainless steel bellows. Through the expansion and bending of bellows, the flexible connectors the pipeline in axial, transverse and angular directions. Flexible connectors can play the following roles:
1. The flexible connectors absorbs the axial, transverse and angular thermal deformation of the pipeline.
2. Flexible connectors can absorb equipment vibration and reduce the influence of equipment vibration on pipeline.
3. Flexible connectors can absorb the pipeline deformation caused by earthquake and land subsidence.
Technique Parameter of flexible connectors
|
Diameter (mm)
|
Pressure grade |
Available Area of Bellows (c㎡)
|
Max Size of External Diameter
|
Length |
|||
|
1.0 |
1.6 |
2.5 |
Flange
|
Tube
|
|||
|
32
|
20/26
|
18/63
|
15/98
|
16
|
225
|
160/250
|
264/280
|
|
40
|
20/24
|
18/89
|
15/98
|
23
|
244
|
164/259
|
269/289
|
|
50
|
20/70
|
18/70
|
15/106
|
37
|
259
|
172/276
|
282/306
|
|
65
|
26/44
|
22/55
|
15/138
|
55
|
270
|
215/294
|
300/322
|
|
80
|
34/33
|
28/41
|
19/68
|
81
|
284
|
240/338
|
344/366
|
|
100
|
40/75
|
35/93
|
25/54
|
121
|
304
|
235/317
|
323/345
|
|
125
|
38/59
|
34/74
|
29/117
|
180
|
334
|
282/314
|
316/342
|
|
150
|
40/62
|
34/78
|
29/92
|
257
|
364
|
282/339
|
338/367
|
|
200
|
59/52
|
53/58
|
46/65
|
479
|
442
|
340/402
|
402/426
|
|
250
|
87/35
|
79/39
|
48/78
|
769
|
507
|
393/459
|
493/399
|
|
300
|
87/37
|
79/41
|
71/47
|
1105
|
562
|
464/525
|
564/565
|
|
350
|
87/44
|
79/48
|
71/45
|
1307
|
622
|
509/564
|
609/604
|
|
400
|
87/43
|
79/47
|
71/47
|
1611
|
562
|
522/566
|
622/628
|
|
450
|
87/37
|
79/41
|
47/75
|
1972
|
700
|
403/498
|
503/523
|
|
500
|
87/68
|
79/75
|
71/45
|
2445
|
760
|
431/523
|
531/554
|
|
600
|
87/85
|
79/94
|
71/82
|
3534
|
835
|
478/548
|
578/588
|
|
700
|
87/77
|
79/85
|
71/103
|
4717
|
1110
|
490
|
590
|
|
800
|
102/102
|
94/112
|
71/95
|
5822
|
1265
|
502
|
602
|
|
900
|
102/97
|
94/107
|
80/123
|
7620
|
1186
|
/
|
698
|
|
1000
|
102/105
|
94/106
|
82/117
|
9043
|
1286
|
/
|
692
|
Flexible connectors details show
Production process of flexible connectors
Do you know how is a high quality flexible connectors made?Let's see with JINGNING.
Flexible connectors can be processed into different types according to different needs
Jingning has more than 17 years of design experience in manufacturing flexible connectors, rubber expansion joint, metal bellows joint, disassembly joint, pipeline and other industrial pipe fittings. The flexible connectors meets the international standards such as GB, ISO, DIN, ANSI, BS, JIS and the special requirements of customers.
Flexible connectors advantages
1. Flexible connectors is ex factory price
2. 17 years manufacturing experience, 5 years export experience
3. The flexible connectors has strict quality inspection, and the quality far exceeds the industry standard.
4. Various specifications of flexible connectors mold base customization and OEM
5. Free flexible connectors samples
6. Large inventory of flexible connectors
Flexible connectors application
Because of its flexibility, flexible connectors can compensate the temperature difference deformation or other deformation between equipment and pipeline, prevent vibration, reduce the thrust of pipeline on equipment, and adapt to the uneven settlement of oil tank foundation. The flexible connectors can be widely used in chemical industry, oil refining, electric power, light industry, atomic energy, metallurgy, machinery, instrument, ship, aerospace and other departments. With the wide application of power pipeline and heat pipeline in industry and civil field, the requirement of flexible connectors is higher and higher.
