Marine Grade Flanged Rubber Expansion Bellows: Shock-Absorbing Sea Water Pipeline Connector for Ships
Product Description
Operating in harsh maritime environments leaves no room for compromise; shipboard piping systems must endure relentless kinetic stress and aggressive chemical assaults. Engineered specifically for demanding marine and offshore duties, this premium-grade flanged rubber expansion bellows delivers a robust, highly resilient structural interface for vessel engine rooms, ballast networks, and auxiliary cooling loops. It serves as a vital safeguard against severe salt-water corrosion, localized ambient engine room heat, and the destructive potential of galvanic action caused by joining dissimilar marine metal alloys.
Unlike standard industrial connectors, this specialized maritime bellows features a highly flexible, multi-layered elastomeric body specifically calibrated to absorb the relentless multi-axis twisting forces, structural racking, and hull deflections experienced by vessels navigating turbulent open seas. By isolating the heavy mechanical vibrations of primary propulsion engines and generator sets, it effectively prevents critical sea-water cooling conduits from shearing or developing micro-fractures. Compact, exceptionally tough, and designed to meet stringent maritime safety benchmarks,
Performance characteristics
-
Anti-Galvanic Isolation Framework : The heavy-duty rubber body provides a complete physical and electrical break between connected metal piping components. This eliminates the risk of galvanic/electrolytic corrosion typically caused by seawater running through mismatched copper-nickel, steel, or bronze alloys.
-
Severe Marine Environment Resilience: Formulated using a high-density, specialized elastomeric compound (such as high-grade EPDM or Neoprene) that delivers superior resistance to salt spray, ozone aging, direct UV degradation, and the intense ambient heat of enclosed vessel engine rooms.
-
Hull-Deflection Torsional Absorption:Engineered with advanced structural flexibility to simultaneously neutralize severe axial, lateral, and angular movements. It effortlessly flexes under the complex twisting forces and structural bending caused by wave impact and ship hull flexing.
Product Specification
| Size |
Length |
Allowable Movements in Operation |
| mm |
inch |
mm |
Axial Compression mm |
Axial Extension
mm |
Transverse Movement
mm
|
Angular Deflection mm |
|
| 25 |
1 |
130/152 |
20 |
12 |
14 |
15° |
| 32 |
1 1/4 |
95/130/152 |
20 |
12 |
14 |
15° |
| 40 |
1 1/2 |
95/130/152 |
20 |
12 |
14 |
15° |
| 50 |
2 |
105/130/152 |
20 |
12 |
14 |
15° |
| 65 |
2 1/2 |
115/130/152 |
20 |
12 |
14 |
15° |
| 80 |
3 |
130/135/152 |
20 |
12 |
14 |
15° |
| 100 |
4 |
130/152 |
20 |
12 |
14 |
15° |
| 125 |
5 |
130/152/165 |
20 |
12 |
14 |
15° |
| 150 |
6 |
130/152/185 |
20 |
12 |
14 |
15° |
| 200 |
8 |
130/152/210 |
20 |
12 |
14 |
15° |
| 250 |
10 |
130/203/230 |
20 |
12 |
14 |
15° |
| 300 |
12 |
130/203/245 |
25 |
16 |
22 |
15° |
| 350 |
14 |
200/255 |
25 |
16 |
22 |
15° |
| 400 |
16 |
200/255 |
25 |
16 |
22 |
15° |
| 450 |
18 |
200/255 |
25 |
16 |
22 |
15° |
| 500 |
20 |
200/255 |
25 |
16 |
22 |
15° |
| 600 |
24 |
260 |
25 |
16 |
22 |
15° |
| 700 |
28 |
260 |
25 |
16 |
22 |
15° |
| 800 |
32 |
260 |
25 |
16 |
22 |
15° |
| 900 |
36 |
260 |
25 |
16 |
22 |
15° |
| 1000 |
40 |
260/300 |
25 |
16 |
24 |
15° |
| 1100 |
44 |
300 |
25 |
16 |
24 |
15° |
| 1200 |
48 |
300 |
25 |
16 |
24 |
15° |
|
Note: If the medium is oil, acidic or alkaline substances, and there are special requirements for the working temperature, you can customize it by sending a letter or drawing. Please specify when ordering
|
Product Details
Production Flow
|
1.Raw material
Top level CR/EPDM/NBR
rubber raw materials,
No recycled rubber
|
2.Plasticating and mixing
Special Formulation for better Bending with Nylon,For Better Strength,Sealing
|
3.Workblanks wraping
Cooper plated steel wire reinforcement prevent pull off
|
|
4.Vulcanizing
Automatic vulcanization machine ensure vulcanization time and pressure
|
5.Inspecting
100% strict inspection is to be responsible for consumers
|
6. Packaging
Protective Packaging for No
Rust and Breakage
|
Application
Flexible Joint Flange are widely used in various fields, including construction, chemical industry, shipbuilding, tap water, gas, chemical pipelines, petroleum pipelines, food pipelines, air conditioning pipelines, and sewage treatment.
Our Services
1.24-hour online
2.Free samples provided
3.Support customization
4.Provide drawings
5.Multiple payment styles to choose from
6.Factory inspection (material, specifications, quantity, pressure, packaging)
7.Long warranty period
8.Suitable packaging for transportation
Our Customer
Certificate
FAQ
Q: Will marine organisms or barnacles ruin the rubber?
A: Our specialized smooth rubber lining resists marine bio-fouling and keeps seawater flowing smoothly without catching debris.
Q: Are the flanges rustproof for offshore salt spray?
A: The flanges are heavily hot-dip galvanized or made of stainless steel to provide premium corrosion defense against ocean spray.
