Factory Can be Customized PTFE Bellow in Piping with Carbon Steel Flange
PTFE bellow in piping serves as a pressure-compensating component in piping systems, engineered to absorb dimensional changes caused by thermal cycles or pipeline misalignment. Its multi-arch geometry provides multidirectional flexibility, preventing stress concentration in critical infrastructure such as chemical reactors, cryogenic transfer lines, and exhaust systems requiring gas-tight, contamination-free operation.
Performance characteristics
The main features of PTFE bellow in piping serves include:
1. Corrosion resistance
2. High temperature stability
3. Sealing performance
4. Widely used
5. Eliminate installation errors
In summary, pure PTFE bellow in piping serves have become indispensable and important equipment in the industrial field due to their unique material properties and excellent performance.
Product Specification
|
Diameter
(mm)
|
Pressure grade
(Mpa) |
Available Area
of Bellows
(c㎡)
|
Max Size of
External Diameter
(mm)
|
Length
(mm) |
| 1.0 |
1.6 |
2.5 |
Flange |
Tube |
| 32 |
20/26 |
18/63 |
15/98 |
16 |
225 |
160/250 |
264/280 |
| 40 |
20/24 |
18/89 |
15/98 |
23 |
244 |
164/259 |
269/289 |
| 50 |
20/70 |
18/70 |
15/106 |
37 |
259 |
172/276 |
282/306 |
| 65 |
26/44 |
22/55 |
15/138 |
55 |
270 |
215/294 |
300/322 |
| 80 |
34/33 |
28/41 |
19/68 |
81 |
284 |
240/338 |
344/366 |
| 100 |
40/75 |
35/93 |
25/54 |
121 |
304 |
235/317 |
323/345 |
| 125 |
38/59 |
34/74 |
29/117 |
180 |
334 |
282/314 |
316/342 |
| 150 |
40/62 |
34/78 |
29/92 |
257 |
364 |
282/339 |
338/367 |
| 200 |
59/52 |
53/58 |
46/65 |
479 |
442 |
340/402 |
402/426 |
| 250 |
87/35 |
79/39 |
48/78 |
769 |
507 |
393/459 |
493/399 |
| 300 |
87/37 |
79/41 |
71/47 |
1105 |
562 |
464/525 |
564/565 |
| 350 |
87/44 |
79/48 |
71/45 |
1307 |
622 |
509/564 |
609/604 |
| 400 |
87/43 |
79/47 |
71/47 |
1611 |
562 |
522/566 |
622/628 |
| 450 |
87/37 |
79/41 |
47/75 |
1972 |
700 |
403/498 |
503/523 |
| 500 |
87/68 |
79/75 |
71/45 |
2445 |
760 |
431/523 |
531/554 |
| 600 |
87/85 |
79/94 |
71/82 |
3534 |
835 |
478/548 |
578/588 |
| 700 |
87/77 |
79/85 |
71/103 |
4717 |
1110 |
490 |
590 |
| 800 |
102/102 |
94/112 |
71/95 |
5822 |
1265 |
502 |
602 |
| 900 |
102/97 |
94/107 |
80/123 |
7620 |
1186 |
/ |
698 |
| 1000 |
102/105 |
94/106 |
82/117 |
9043 |
1286 |
/ |
692 |
Note: If the medium is oil, acidic or alkaline substances, and there are special requirements for the working temperature, you can customize it by sending a letter or drawing. Please specify when ordering.
